Max. swing diamete(mm)：320
Max. swing diameter over cross slide(mm)：110
Spindle rod thread：M48*1.5
Spindle head type：A2-5
Taper of spindle bore：21°
X rapid travel speed(mm/min)：12000
Z servo motor torque(Nm)：110/6
Max. Swing Diameter (mm)：320
Max. Spindle Speed (r.p.m)：3000 r.p.m
Machining Capacity：Medium Duty
Spindle Bore(mm)：49
Width of bed (mm)：500 mm
Spindle Motor Power(kW)：4
No. of Spindles：Single
Max. Turned Length (mm)：350
Number of Axes：2
Travel (X Axis)(mm)：560 mm
Positioning Accuracy (mm)：0.005
